Positive Pressure Conveying Case: DAP Powder in Queensland

Keywords: Pneumatic conveying case, Oceania pneumatic conveying, Queensland pneumatic conveying.

This case study presents a successful positive pressure pneumatic conveying system for DAP powder at a client facility in Queensland, Australia. The project was designed, manufactured, and commissioned by Shandong Headpowder Engineering Co., Ltd., known as headpowder, a leading Chinese engineering company specializing in powder handling and pneumatic conveying. Headquartered in Shandong, China, the company has extensive experience delivering turnkey projects across the globe, including Oceania, where this Queensland installation has become a reference for reliability and efficiency.

The customer in Queensland required a robust, dust-free method to transfer DAP powder from storage silos to a processing line. DAP, or di-ammonium phosphate, is a widely used fertilizer with high moisture absorption and abrasive characteristics, which makes conveying challenging. Traditional mechanical conveyors were prone to clogging and leakage, causing material waste and maintenance downtime. To overcome these issues, headpowder proposed a positive pressure pneumatic conveying system, which uses compressed air to push the powder through a sealed pipeline. This closed-loop design ensures zero dust emission, minimal product loss, and safe operation in harsh environments.

During the engineering phase, headpowder’s team analyzed the physical properties of DAP powder, including particle size distribution, bulk density, moisture content, and flowability. This data was essential for determining the correct conveying velocity, air-to-material ratio, and pipeline diameter. Positive pressure conveying was selected because it provides superior flexibility for long-distance conveying and multiple discharge points. The Queensland plant operates with a conveying distance of roughly 120 meters and a capacity of 25 tons per hour, which the system achieves with stable performance and low energy consumption.

The system consists of a pressure vessel (blow tank) that feeds DAP powder into the conveying line, a high-pressure roots blower that supplies clean air, diverter valves for routing material to different destinations, and high-efficiency bag filters at receiving silos for separating air and powder. The blow tank includes a specially tapered outlet to prevent arching and flushing, ensuring a continuous and uniform flow. All components are made of wear-resistant materials and coated with anti-corrosion layers, extending service life and reducing maintenance. The automation system uses PLC and HMI, allowing operators to monitor pressure, airflow, and material level in real time.

One major challenge on this Oceania project was meeting the site’s strict safety and environmental regulations. The system was therefore engineered with pressure relief valves, explosion-proof electrical enclosures, and grounding equipment to prevent static accumulation. The enclosed pipeline eliminates contact between operators and the abrasive DAP dust, improving workplace safety. In addition, variable frequency drives on the blower motor allow the conveying speed to be adjusted based on real-time demand, maximizing energy savings and reducing the carbon footprint.

Installation and commissioning were completed on schedule, with headpowder engineers supervising on-site in Queensland. The local contractor worked closely with the Chinese specialists, and comprehensive training was provided to plant operators. After startup, the customer confirmed that conveying efficiency increased by 30 percent compared to their previous mechanical equipment, while maintenance costs dropped significantly. The positive pressure system also enabled better plant layout because the flexible pipeline could be routed over existing equipment without structural modifications.

This successful DAP powder conveying case demonstrates headpowder’s capability in executing international projects with high standards. By combining advanced engineering with practical operational experience, the company has become a trusted partner in the Oceania market and beyond. Whether for a simple conveying line or a complete powder handling system, headpowder offers customized solutions from initial design to after-sales support.
