A pneumatic diverter valve is a key component in pneumatic conveying systems. It changes the direction of powders, granules, and other bulk solids from one pipeline to two or more downstream lines. This allows product to be sent to different silos, bins, or processing machines without stopping the conveying system. Pneumatic control makes switching fast, accurate, and easy to automate.

As a professional pneumatic diverter valve manufacturer and supplier, we provide pneumatic control diverter valves for pneumatic conveying systems at competitive factory prices. Our products are widely used in food, feed, chemical, cement, mineral, plastic, and pharmaceutical industries. They are designed for reliable operation in both dilute-phase and dense-phase conveying, and they ensure stable material routing with minimal product degradation.

The working principle is simple. A pneumatic cylinder drives a rotating flap or sliding plate inside the valve body. When compressed air is supplied through a solenoid valve, the internal passage changes position and directs the material to the desired outlet. Switching can be controlled manually, automatically, or through a PLC system for complete integration into a production line.

Standard configurations include two-way, three-way, four-way, and multi-port diverter valves. The connection options are flanged, threaded, or clamp type to match different pipeline systems. Compact housings allow installation in limited spaces, and various actuator sizes provide the right torque for smooth operation. Custom ports and bore sizes are available to meet specific process needs.

High-quality materials are used to ensure long service life. The valve body can be manufactured in carbon steel, stainless steel 304, or stainless steel 316L. For abrasive materials, the inner surfaces and diverter plate may be lined with wear-resistant ceramics, polyurethane, or rubber. Precision sealing parts prevent leakage and cross-contamination, protecting product quality and improving the efficiency of the whole conveying line.

The main features of our pneumatic control diverter valve include fast switching response, stable flow direction, low pressure loss, compact structure, and low maintenance requirements. Because the valve is driven by air pressure, it is safe for operation in dusty and harsh environments. Additional accessories such as position limit switches, inductive sensors, and flow control valves are available for remote monitoring and precise control.

These valves are suitable for handling flour, starch, sugar, salt, milk powder, yeast, feed ingredients, plastic pellets, rubber granules, cement, fly ash, lime, quartz sand, bentonite, and many chemical additives. They are commonly installed in pneumatic conveying lines with diameters from DN50 to DN300. Non-standard sizes and pressure ratings can be produced to match your existing equipment and system design.

Every valve is tested before delivery to ensure reliable performance. Tests include pressure testing, air tightness testing, switching action testing, and electrical signal verification. Strict quality control is maintained throughout welding, machining, assembly, and final inspection. This helps reduce installation problems and breakdowns, giving operators confidence in the pneumatic conveying system.

To choose the correct pneumatic diverter valve, consider material bulk density, particle size and shape, conveying velocity, pressure range, temperature, control voltage, and required switching frequency. We provide professional selection advice and can customize the actuator, sealing material, body material, and connection type. Our goal is to ensure long product life and efficient performance in your process.

Contact our factory for detailed drawings, technical specifications, and current pneumatic diverter valve price. We welcome OEM and ODM orders, and we are ready to offer a cost-effective solution for your bulk handling plant. With short lead times and responsive after-sales service, we are your reliable partner for pneumatic conveying components.
