Headpowder, the engineering brand of Shandong Headpowder Engineering Co., Ltd., is headquartered in Shandong Province, China. The company successfully designed, manufactured, shipped, and commissioned a comprehensive high-purity pneumatic conveying system for lithium ceramic powder at a production facility in Christchurch, New Zealand. This project has quickly become a reference installation for the Oceania region and is described here in full as a detailed case study covering the original challenge, the engineering approach, and the measurable outcomes achieved.

Christchurch is the largest city on the South Island of New Zealand and enjoys a strong reputation for innovative technology and sustainable manufacturing. The local client produces lithium ceramic powder, which is a critical raw material for high-performance lithium batteries, advanced solid-state energy storage systems, and technical ceramics used in demanding electronics and automotive applications. The purity of this powder is absolutely essential; even a few parts per million of iron, copper, or other impurities can harm battery capacity, increase internal resistance, or cause premature failure. Therefore, the entire material handling process must exclude any source of contamination, including wear debris, moisture, ambient dust, and residual lubricants.

Previously, the plant used manual transfer from drums into process hoppers. That method was dusty, labor-intensive, and inconsistent. It also exposed operators to fine powder, allowed moisture uptake, and created frequent batch-to-batch fluctuations. The client decided that future growth required a fully enclosed, automated, high-purity conveying line. After evaluating potential partners from Europe, Asia, and Oceania, the customer selected Headpowder because of its proven expertise in difficult and high-purity powders, its flexible custom engineering, and its clear project management structure.

The central technical challenge was to move fine, abrasive, and semi-conductive lithium ceramic powder over a horizontal distance of 65 meters and a vertical lift of 18 meters while maintaining impeccable purity. Standard dilute-phase pneumatic conveying was unsuitable because high gas velocities would erode pipe surfaces and cause particle breakage. Mechanical conveyors were also ruled out because of contact friction, lubrication risks, and severe wear. Headpowder therefore designed a dense-phase pneumatic conveying system operating under low velocity with an accurate aeration strategy. A pressure vessel, or sender, pressurizes a batch of powder to approximately 2.5 bar gauge. Along the pipeline, a sequence of stream splitter and aeration fittings creates a stable moving-bed flow, moving the powder gently and continuously without excessive turbulence.

All product contact parts were manufactured from 316L stainless steel with an interior surface roughness of no more than Ra 0.6 micrometres. Pipe joints were precision orbital TIG welded and then electropolished to remove microscopic roughness and crevices. All bends were long-radius construction to reduce local abrasion and particle impact. Seals and gaskets were made of EPDM and PTFE, and no copper, zinc, or carbon steel was allowed in contact with the conveyed powder. Before shipment, Headpowder conducted a simulated conveying trial at its own test facility. The test measured iron pickup from the pipeline at less than 0.5 ppm per hour of continuous operation, comfortably meeting the customer’s requirement.

To satisfy the high-purity requirement, the conveying gas was filtered nitrogen with a purity of 99.999%. The nitrogen passes through a refrigerating dryer and a series of HEPA filters, guaranteeing a dew point below -50°C and an oxygen concentration maintained below 0.5%. This inert, dry environment prevents lithium ceramic powder from reacting with atmospheric moisture or carbon dioxide, which could otherwise form impurities on particle surfaces. The system recycles and cleans the nitrogen after each cycle, reducing operating costs while preserving perfect process safety. Additionally, the discharge station is equipped with a reverse-jet filter system that separates powder from gas without opening the line to surrounding air.

The entire system is automatically controlled by a Siemens PLC and an operator-friendly HMI. High-precision load cells in the sender determine the exact batch weight, after which the valve sequence begins automatically. During conveying, in-line pressure transmitters send continuous readings to the controller. The controller adjusts the opening of aeration valves to keep the product moving in reliable plug flow. If any section shows a tendency to block, additional air injection is applied automatically. The system delivers a steady conveying rate of 3.2 tons per hour while using only 4.5 normal cubic metres of gas per ton of product, demonstrating excellent energy efficiency.

Safety engineering was another essential layer of this project. Lithium ceramic powder can form explosive dust clouds under certain conditions, so the system was designed with the highest level of preventive protection. The entire pipeline is electrically bonded and grounded to prevent static charge accumulation. The pressure vessel and receiving hopper have explosion vent panels oriented toward a safe external area. Fast-acting isolation valves stop the process automatically if high temperature or a rapid pressure rise is detected. The control software is interlocked with the plant’s fire alarm system, allowing immediate shutdown of the conveying line during any site-wide emergency. These safety measures satisfy New Zealand’s stringent occupational health and environmental regulations.

Headpowder delivered the complete solution as a modular, skid-mounted unit. Each module was fabricated, preassembled, and factory-tested in Shandong, then disassembled into shipping sections. The equipment was carefully packed into sea containers and transported from Qingdao Port to Lyttelton Port near Christchurch. A senior Headpowder engineer travelled to the site to supervise installation, integration, and commissioning. The local operations and maintenance teams received structured training in normal operation, routine maintenance, troubleshooting, and emergency response. The full project, from design approval to successful startup, was completed in less than six months, with over 95 percent of schedule milestones achieved on time.

After the installation, a formal 72-hour validation test was carried out. The results exceeded the contract targets in every important category. The actual conveying capacity reached 3.4 tons per hour, six percent higher than the guaranteed figure. Final product purity showed no measurable increase in iron, chromium, or other metallic impurities. The moisture content at the discharge point stayed below 80 ppm, and the particle size distribution was statistically identical to the inlet material, proving that the dense-phase conveying system caused no degradation. The plant also recorded dust exposure levels far below the New Zealand workplace exposure limits, creating a cleaner and safer environment for all employees.

From an economic and environmental standpoint, the new system has delivered impressive improvements. Product waste due to contamination and manual handling errors has decreased by approximately 2.5 metric tons per year. Energy consumption is roughly 30 percent lower than it would be with a conventional dilute-phase system, because of the low-velocity dense-phase design and efficient nitrogen recycling. Maintenance expenses have been reduced by more than half, since there are no mechanical conveying parts in contact with the powder. Emptying dust emissions practically disappeared, aligning the plant with New Zealand’s strong sustainability goals and helping the client receive production certification for advanced battery materials.

In conclusion, the Christchurch lithium ceramic powder high-purity pneumatic conveying project demonstrates the outstanding capabilities of Shandong Headpowder Engineering Co., Ltd. in solving complex powder handling problems. Headpowder proved that a well-engineered pneumatic conveying system can preserve the high purity and physical integrity of sensitive ceramic powders while delivering excellent productivity and safety. This case also highlights Headpowder’s successful entry into the Oceania market, with a robust project execution model that spans engineering, manufacturing, logistics, installation, and after-sales service. For additional information, to request a reference visit, or to explore a personalised high-purity conveying solution for your own facility, please contact the company at its office in Shandong, China. The responsible sales manager, Mr. Zhang, is available directly via WeChat at 15662777102. Headpowder looks forward to making your powder conveying system as clean, safe, and efficient as this landmark New Zealand project.
