NewInorganicPowderPneumaticConveyingCase,KisumuKenya

NewInorganicPowderPneumaticConveyingCase,KisumuKenya

Keywords: pneumatic conveying case, pneumatic conveying in Africa, positive pressure pneumatic conveying

Kisumu, a major city in western Kenya near Lake Victoria, is experiencing rapid industrial growth. The expanding construction and chemical sectors demand efficient and safe handling of fine powders. This case study describes a positive pressure pneumatic conveying system supplied by Shandong Headpowder Engineering Co., Ltd. (Headpowder) for a new inorganic material plant in Kisumu. This project demonstrates the successful adaptation of Chinese engineered pneumatic technology to African operating conditions.

The plant produces a new type of inorganic powder used as an additive in cement and coatings. This material is slightly abrasive and hygroscopic, with a bulk density of approximately 0.7 t/m³ and D50 of 45 microns. Previously, the factory used manual trolleys and screw conveyors, which generated severe dust, caused material losses, and required frequent maintenance. To improve working conditions and reliability, the customer needed a closed and long-distance conveying solution. The existing old equipment also occupied much floor space and limited plant expansion options.

Headpowder's engineers designed a complete positive pressure pneumatic conveying system. The system operates at a pressure range of 0.1–0.3 MPa and uses an air velocity between 20 and 35 m/s to ensure stable conveying without damaging the particles. Main components include an air compressor, pressure vessel, rotary feeder, DN125 pipeline with ceramic-lined elbows, and reverse-pulse bag filters. The conveying line covers 80 meters horizontally and 15 meters vertically, with a capacity of 5,000 kilograms per hour.

Special attention was paid to the hygroscopic nature of the powder. A drying unit was installed upstream, and fluidized aeration pads prevent bridging at hopper outlets. The control system uses a Siemens PLC with a touchscreen HMI, enabling operators to monitor pressure and flow in real time, set parameters for different products, and receive immediate blockage alerts. A nitrogen-assisted purge function helps clean the pipeline safely during maintenance.

All equipment was manufactured at Headpowder's plant in Shandong Province, China, and shipped via the Port of Mombasa to Kisumu. Since engineers could not travel at that time, Headpowder provided remote commissioning with detailed manuals and video guidance. A local contractor performed installation and wiring. The work was completed in two weeks, and the performance test showed a conveying rate of 5.4 tons per hour, surpassing the design specification by 8%, with stable pressure and no pipeline vibration. The compact skid-mounted layout also minimized installation time and plant footprint.

After three months of operation, the results have been outstanding. Dust emissions are virtually zero, creating a clean and safe work environment. Material loss has been eliminated, saving approximately $30,000 per year. Labor costs dropped by 40%, production availability increased from 85% to 97%, and maintenance costs decreased by 60%. The improved working conditions also boosted worker morale and reduced staff turnover. The customer was highly satisfied with the system and has already discussed an additional project with Headpowder.

Shandong Headpowder Engineering Co., Ltd., abbreviated as Headpowder, is a professional company based in Shandong, China, specializing in pneumatic conveying and bulk material handling. With over ten years of experience and successful projects in more than twenty countries, Headpowder provides engineering design, equipment manufacturing, installation support, and after-sales service for dense-phase and dilute-phase conveying systems. Headpowder also supports clients with after-sales spare parts, remote training, and quick-response technical consultation. For further information about this Kisumu project or customized solutions, please contact Mr. Zhang, Sales Manager, via WeChat: 15662777102.
